Dugard Eagle 850 CNC Vertical Machining Center
Description
Dugard Eagle 850 CNC Vertical Machining Center
Specification:
– CNC control system: Fanuc 0iMD
– Table dimensions: 1000 x 510 mm
– Maximum table load: 500 kg
– T-slot, number x size x spacing: 5 x 18 x 100 mm
– X axis travel: 850 mm
– Axis travel Y: 530 mm
– Z axis travel: 510 mm
– Distance between spindle tip and table axis: 150-660 mm
– Distance between spindle axis and column: 585 mm
– Spindle taper: ISO 40
– Spindle power (constant / 30 min.) KW 11 / 15
– Maximum spindle speed: 10,000 rpm
– Rapid feeds in the axes X, Y, Z: 30/30/24 m / min.
– X, Y, Z feed speed: 1-10000 mm / min.
– X, Y, Z axis guides: rolling blocks
– Positioning accuracy P (according to VDI 3441) mm P 0.005 Repeatability Ps (according to VDI 3441) mm Ps 0.003
– Tool magazine: 24 tools
– Tool holder type: BT40 (option SK40)
– Magazine type: with intermediate clamp
– Maximum tool diameter: 80 mm
– Maximum tool length: 300 mm
– Maximum tool weight: 7 kg
– Tool change time (TT, CC): 2.0-4.5 s
– Power demand: 15 kVA
– Compressed air demand: 5 bar, 200 l / min.
– Required area (LxWxH): 2.30 x 2.12 x 2.58 m
– Machine weight: 5550 kg
Machine equipment :
– spindle: 10,000 rpm, with cooler (liquid cooling)
– drum tool magazine, with intermediate
lug : 24 positions
