GER C-2000 CNC 2 AXIS OD/ID Grinding
OD ID Griding Machine
Specification:
WORKPIECE ENVELOPE
Grinding Length: 2000.000 mm
OD Grinding Diameter(s) Max: 350.000 mm
Swing Diameter: 355.000 mm
Workload: 300 kg.
GRINDING WHEEL AND SPINDLE
Grinding Wheel Dia.: 500.000 mm Width: 80.010 mm Bore: 203.200 mm
Wheel Head Motor: 5.60 kW 2,260 rpm Angle Adjustment: 0.000°
Workhead Motor: 1.40 kW Speed: 2,260 rpm
AXES SPECIFICATIONS
Travel Max Feed Rapid Rate
Longitudinal: 2500.000 mm
Cross: 295.000 mm
Vertical
WEIGHTS AND MEASURES
Machine Length: 5,800 mm
Machine Width: 1,725 mm
Machine Height: 1,950 mm
Machine Weight: 5,500 kg
