Lorenz LS 150 CNC Gear Shaper Machine
CNC Gear Shaper
Specification:
Control: Fanuc OiTF
Max. Outer wheel: Ø 150 * mm
Max. Workpiece diameter with internal teeth: approx. 280 mm
Max. Wheel width: 42 mm
Module range: 0.5-3
Stroke length: 50 mm
Stroke position adjustability: 0 – 70 mm
Projection spindle ./. Machine body: 250 mm
Spindle inside holder: approx. 45 mm
Table size / Ø 250 mm
Table bore: 100 mm
Installation height between table and cutting head: 320 mm
Axial travel of the workpiece slide: approx. 285 mm
