Nakamura SC 250 with Barfeed

SPECS


Chuck Size:	254 mm
Bar Capacity:	51 mm
Power:	15 kW
Max RPM:	5000 rpm


Turning Dia:	300 mm
Machining Length:	689 mm
Sub Spindle:	Yes
Control:	CNC (Fanuc 21i-T)

Travels:
Slide Travel X Axis: 6.988″
Slide Travel Z Axis: 19.685″
Slide Travel Y (Sub Spindle) Axis: +/- 1.614″
Turning Capactiy:
Maxiumum Turning Diameter: 11.8″
Maxiumum Turning Length: 19.7″
Spindle:
Main Spindle Maxiumum Speed: 5,000 RPM
Main Spindle Drive Power: 20/25 HP
Chuck:
Chuck Size: 8″
Bar Capacity: 2″
Turret:
Dodecagonal
Turret Tool Capacity: 12
Size and Weight:
Floor Space (Lenth, Width, Height): 102.28″ x 65.79″ x 71.46″
Weight: 8,377 Pounds
