Reishauer NZA Gear Grinder

Gear Grinder Machine

Specification:

Max wheel diameter: 300 mm
Gear width: 170 mm
Module:
-Min: 0,5
-Max: 5
Max clamping length: 420 mm
Max angle of teeth: 45 grad
Number of teeth: 12
-Min: 12
-Max: 130
Slide stroke: 200 mm
Helical lead:
-Min: 200 mm
-Max: 6000 mm
Max diameter of grinding wheel: 350 mm
Max width of grinding wheel: 84 mm
Total power requirement: 9 kW
Dimensions: 2500x2000x2300 mm
Total weight: 4600 kg
