Studer S40 CNC Cylindrical Grinder
- Home
- Grinding Machine
- Cylindrical Grinding Machine
- Studer S40 CNC Cylindrical Grinder
Enquiry
Category: Cylindrical Grinding Machine
- Description
Description
Description
Technical details
Grinding Diameter | 0,2 – 240 mm |
Centre Height | 125 mm |
Grinding Length | ca. 700 mm |
Speed | 0,0001 – 10.000 mm/min |
Centre Distance | 1.000 mm |
Swivelling Range | 180° |
Grinding Depth | 170 mm |
Turning Speed Range – Spindle | 1.671 – 2.801 min/-1 |
Spindle Bore | 30 mm |
Total Power Requirement | 13,5 kW |
Weight Of The Machine Ca. | 3,8 t |
Dimensions Of The Machine Ca. | 4,0 x 4,8 x 2,5 m |
Max. Dia. Of Grinding Wheel | 510 mm |
Max. Workpiece Weight Between Centres | 100 kg |
Grinding Wheel Hole Diameter | 203,2 mm |
Turning Speed Range – Workpiece | 30 – 750 min/-1 |
Fitting Taper | MK 5 |
Max. Swivel | 8,5 ° |
