TOS VTL SC 27

Enquiry
Category:
Description

Description

  • Specification:Swing: 2630 mm
    Swing with side head: 2600 mm
    Table diameter: 2500 mm
    Max working height: 1900 mm
    Table speed range: 1.24-112 rpm
    Max work-piece weight: 15000 kg
    Right head vertical stroke: 760 mm
    Left head vertical stroke: 1200 mm
    Side head stroke:
    -Horizontal: 900 mm
    -Vertical: 1800 mm
    Cros rail vertical travel: 1600 mm
    Main motor: 60 kW
    Dimensions:
    -Length: 4800 mm
    -Width: 4800 mm
    -Height: 5000 mm
    Machine weight: 38850 kg
